Declarations for various GLUT utilites for a rigid body application. More...

#include "WoRB.h"
#include <GL/freeglut.h>

Include dependency graph for Utilities.h:

This graph shows which files directly or indirectly include this file:

Data Structures
class	WoRB::GLUT_Renderer
	Interface for a GLUT-rendered rigid body. More...
struct	WoRB::GLUT_Renderer::Colorf
	Represents a color defined red, green, blue and alpha channels. More...
class	WoRB::GLTransform
	Establishes temporarily a GL transform from body-fixed into world frame. More...
class	WoRB::GLOrthoScreen
	Establishes temporarily orthogonal projection in screen coordinates. More...
class	WoRB::Ball
	Encapsulates a rigid body with geometry of a sphere. More...
class	WoRB::Box
	Encapsulates a rigid body with geometry of a rectangular parallelepiped. More...
class	WoRB::GLUT_Framework< GlutApplication >
	GLUT wrapper around a single instance of a GlutApplication template class. More...
Namespaces
namespace	WoRB
Defines
#define	GLUT_DISABLE_ATEXIT_HACK
	Disable GLUT ataxit workaround on windows.
Functions
double	WoRB::RandomReal ()
	Gets a uniform real number in range [0,1).
Quaternion	WoRB::RandomQuaternion (double length=1.0)
	Gets a quaternion of the given length having a random orientation.
Quaternion	WoRB::RandomQuaternion (const Quaternion &min, const Quaternion &max)
	Gets a random quaternion uniformly distributed in a 4D box.
void	WoRB::RenderText (double x, double y, double z, const char *text)
	Renders the given text to the given location in body-fixed space.
int	WoRB::RenderPrintf (int x, int y, const char *format,...)
	Renders the given text to the given location in screen space on the window.
void	WoRB::RenderStateVariables (const RigidBody &body, const Quaternion &extent)
	Draws the geometry axes, angular velocity and angular momentum.
void	WoRB::RenderAxes (double length)
	Draws the world axes.
void	WoRB::Pause (unsigned long ms)
	Pauses execution for the given amount of milliseconds.
void	WoRB::glutForegroundWindow ()
	Brings the current GLUT window to the foreground.

Detailed Description

Declarations for various GLUT utilites for a rigid body application.

Author:: Mikica B Kocic

Version:: 0.2

Date:: 2012-05-10

Copyright:: GNU Public License.

Definition in file Utilities.h.

Define Documentation

#define GLUT_DISABLE_ATEXIT_HACK

Disable GLUT ataxit workaround on windows.

Win32 has an annoying issue where there are multiple C run-time libraries (CRTs). If the executable is linked with a different CRT from the GLUT DLL, the GLUT DLL will not share the same CRT static data seen by the executable. In particular, atexit callbacks registered in the executable will not be called if GLUT calls its (different) exit routine). GLUT is typically built with the "/MD" option (the CRT with multithreading DLL support), but the Visual C++ linker default is "/ML" (the single threaded CRT).

One workaround to this issue is requiring users to always link with the same CRT as GLUT is compiled with. That requires users supply a non-standard option. GLUT 3.7 has its own built-in workaround where the executable's "exit" function pointer is covertly passed to GLUT. GLUT then calls the executable's exit function pointer to ensure that any "atexit" calls registered by the application are called if GLUT needs to exit.

To avoid the atexit workaround, define GLUT_DISABLE_ATEXIT_HACK.

Definition at line 39 of file Utilities.h.
