The Particle encapsulates both particle physical properties and visual properties needed for rendering during animation. More...

Collaboration diagram for Particle:

[legend]

List of all members.

Public Member Functions
	Particle (WorldOfParticles parent, double M, double Q, double X, double Y, double R, double T)
	Creates a new instance of Particle.
double	getX ()
	Gets the x-component of particle position.
double	getY ()
	Gets the y-component of particle position.
double	getKineticEnergy ()
	Gets the kinetic energy for the particle.
void	dump ()
	Dumps x/y-components of position, velocity and acceleration to `System.out`.
void	resetVelocity ()
	Resets velocity and acceleration for particle to 0.
void	makeCentripetalVelocity ()
	Makes velocity centripetal to acceleration.
void	resetForce ()
	Resets total force to 0 ( so it could be summed up again).
void	addForceFromParticle (Particle p)
	Calculates particular force that acts on `this` particle when interacting with some other remote particle `p`.
void	applyForce ()
	Applies accumulated (summed up) total force on the particle.
void	moveParticle (double dx, double dy)
	Moves the particle (overriding forces) and resets its velocity.
void	forceBarrier (WorldOfParticles.Barrier barrier)
	Keeps the particle inside infinite potential barrier.
void	paint (Graphics gr, boolean annotate)
	Renders the particle in Graphics context.
void	kill ()
	Kills the particle by setting particle's life time to 0.
void	interruptibleSleep (long millis)
	Thread.sleep wrapper.
void	run ()
	Main thread that solves Newton's laws of motion, effectively moving the particle in the parent `WorldOfParticles` (unless the world is paused i.e.
Private Member Functions
void	initBlurTrail (int size)
	Creates blur trail context (faded ghost images for particle)
void	integrateNewtonLaws (double dT)
	Moves the particle using numerical integration of differential equations of the motion by Euler's method.
void	drawGradCircle (Graphics2D g2d, float x, float y, float radius, Color color)
	Draws the circle with radial gradient from the center.
void	createParticleImage ()
	Creates the image of the particle that will be animated.
Private Attributes
WorldOfParticles	world
	Particle always belong to some world of particles.
double	mass = 1
double	charge = 1
double	radius = 1
double	xPos = 0
double	yPos = 0
double	vx = 0
double	vy = 0
double	vsq = 0
double	ax = 0
double	ay = 0
double	asq = 0
double	Fx = 0
double	Fy = 0
double	lifeTime = Double.POSITIVE_INFINITY
	Particle's life time.
Thread	mainThread
	Each object (i.e.
BufferedImage	image = null
	Image of the particle that is rendered during animation.
Color	color = Color.BLUE
	Particle color.
int	aliasedEdges = 10
	Depth (levels) of anti-aliased edges (anti-aliasing disabled if 0).
boolean	showTrail = false
int	trailSize = 0
int	trailRatioC = 0
int	trailRatio = 0
int[]	trailX = null
int[]	trailY = null
float[]	trailFade = null
Static Private Attributes
static final double	k_e = 5e6
static final double	k_G = 1e-5
static final double	k_x = 1e-4
static final double	minRsq = 91
static final double	maxVsq = 4e4

Detailed Description

The Particle encapsulates both particle physical properties and visual properties needed for rendering during animation.

Physical behavior of the particle is governed by gravitational and electrical forces conducted by Newton's law of motion in form of differential equations (applied to particle's mass, charge, position, velocity and acceleration) and solved (integrated) using numerical Euler's method. Each particle has separate thread integrating equations thus effectively "moving" particle.

Forces acting on the particle are set by particle's WorldOfParticle that overviews interactions between all particles and calculates summary forces for each single particles.

The resulting 'motion' of the particle is then rendered to WorldOfParticle's Graphics context. Particle image is generated once and kept in image internal object. Charged particles are either rendered in Red (positive) or Green (negative). Neutral particles are rendered in Blue.

Author:: Mikica B Kocic

Definition at line 37 of file Particle.java.

Constructor & Destructor Documentation

Particle.Particle	(	WorldOfParticles	parent,
		double	M,
		double	Q,
		double	X,
		double	Y,
		double	R,
		double	T
	)

Creates a new instance of Particle.

Parameters:

parent	the world to which `Particle` belongs to
M	mass of the `Particle`
Q	electrical charge of the `Particle`
X	initial position, x-component
Y	initial position, y-component
R	radius range (0 for random radius)
T	life time in seconds

Definition at line 123 of file Particle.java.

References asq, ax, ay, charge, color, initBlurTrail(), lifeTime, mainThread, mass, radius, vsq, vx, vy, world, xPos, and yPos.

    {
        world    = parent;
        mass     = M;
        charge   = Q;
        lifeTime = T;

        /* Initial position
         */
        xPos = X;
        yPos = Y;

        /* Random initial velocity
         */
        vx   = -100 + 200 * Math.random ();
        vy   = -100 + 200 * Math.random ();
        vsq  = Math.pow( vx, 2 ) + Math.pow( vy, 2 );

        /* No initial acceleration
         */
        ax   = 0;
        ay   = 0;
        asq  = 0;

        /* If the radius is not specified (<=0) then randomize radius
         */
        radius = R > 0 ? R : 10.0 + ( 10.0 - R ) * Math.random ();

        /* Set color depending on charge: Blue (0), Green (+) Red (-)
         */
        if ( charge == 0 ) {
            color = new Color( 0, 0, 1f );
        } else if ( charge > 0 ) {
            color = new Color( (float)charge, 0, 0 );
        } else {
            color = new Color( 0, -(float)charge, 0 );
        }

        /* Setup ghost trail
         */
        initBlurTrail( 10 );

        /* Start moving (solving differential equations for) the particle...
         */
        mainThread = new Thread( this );
        mainThread.start ();
    }

Member Function Documentation

void Particle.addForceFromParticle ( Particle p )

Calculates particular force that acts on this particle when interacting with some other remote particle p.

Parameters:

p	remote particle

Definition at line 273 of file Particle.java.

References charge, Fx, Fy, k_e, k_G, mass, minRsq, xPos, and yPos.

    {
        if ( p == this ) {
            return;
        }

        /* Rsq = squared distance R between particles
         */
        double Rsq = Math.pow( p.xPos - xPos, 2 )
                   + Math.pow( p.yPos - yPos, 2 );

        /* Quantum-mechanics allows distances between particles above some limit
         * (like Pauli's Exclusion Principle and nuclear forces)
         * This suppresses that we have infinite interaction forces between particles.
         */
        if ( Rsq < minRsq ) {
            Rsq = minRsq;
        }

        /* Radius vector Cartesian coordinate components
         */
        double cos = ( p.xPos - xPos ) / Math.sqrt( Rsq );
        double sin = ( p.yPos - yPos ) / Math.sqrt( Rsq );

        /* Coulomb's force between electrical charges
         */
        double e_force = -k_e * charge * p.charge / Rsq;
        Fx += e_force * cos;
        Fy += e_force * sin;

        /* Gravitational force between particle masses
         */
        double g_force = k_G * mass * p.mass / Rsq;
        Fx += g_force * cos;
        Fy += g_force * sin;
    }

void Particle.applyForce ( )

Applies accumulated (summed up) total force on the particle.

Definition at line 313 of file Particle.java.

References asq, ax, ay, Fx, Fy, k_x, mass, maxVsq, vsq, vx, and vy.

    {
        ax = Fx / mass;
        ay = Fy / mass;

        /* Introduce additional drag-force for velocities > sqrt(maxVsq)
         * to slow-down very fast particles.
         */
        if ( vsq > maxVsq ) {
            ax += -k_x * vsq * vx / Math.sqrt( vsq );
            ay += -k_x * vsq * vy / Math.sqrt( vsq );
        }

        asq = Math.pow( ax, 2 ) + Math.pow( ay, 2 );
    }

void Particle.createParticleImage ( ) [private]

Creates the image of the particle that will be animated.

Definition at line 419 of file Particle.java.

References aliasedEdges, color, drawGradCircle(), WorldOfParticles.getGraphicsConfiguration(), image, radius, and world.

Referenced by paint().

    {
        GraphicsConfiguration gc = world.getGraphicsConfiguration ();
        if ( gc == null ) {
            return;
        }

        int diameter = (int)( radius * 2 );

        image = gc.createCompatibleImage( diameter, diameter, Transparency.TRANSLUCENT );

        Graphics2D gImg = image.createGraphics ();
        if ( aliasedEdges > 0 )
        {
            drawGradCircle(gImg, (int)radius, (int)radius, (int)radius, color );
        }
        else
        {
            gImg.setColor( color );
            gImg.fillOval( 0, 0, diameter, diameter );
        }

        gImg.dispose ();
    }

void Particle.drawGradCircle	(	Graphics2D	g2d,
		float	x,
		float	y,
		float	radius,
		Color	color
	)		`[private]`

Draws the circle with radial gradient from the center.

Definition at line 393 of file Particle.java.

Referenced by createParticleImage().

    {
        Point2D center = new Point2D.Float( x, y );

        float[] dist = { 0.0f, 1.0f };

        float[] c = { color.getRed()/255f, color.getGreen()/255f, color.getBlue()/255f };
        Color[] colors = {
                new Color( c[0] * 1.0f, c[1] * 1.0f, c[2] * 1.0f, 1.0f ), // base color
                new Color( c[0] * 0.8f, c[1] * 0.8f, c[2] * 0.8f, 0.0f )  // fade out
                };

        g2d.setPaint(
                new RadialGradientPaint(
                        center, radius, dist, colors, CycleMethod.NO_CYCLE
                        )
                );

        g2d.fill( new Ellipse2D.Float( x - radius, y - radius, 2*radius, 2*radius ) );
    }

void Particle.dump ( )

Dumps x/y-components of position, velocity and acceleration to System.out.

Definition at line 236 of file Particle.java.

References ax, ay, lifeTime, vx, vy, xPos, and yPos.

    {
        System.out.printf( "%8.1f %8.1f %8.1f %8.1f %8.1f %8.1f %8.1f\n",
                           lifeTime, xPos, yPos, vx, vy, ax, ay );
    }

void Particle.forceBarrier ( WorldOfParticles.Barrier barrier )

Keeps the particle inside infinite potential barrier.

Parameters:

barrier boundaries of infinite potential barrier given as array {x1,y1,x2,y2} of coordinates

Definition at line 347 of file Particle.java.

References vx, vy, xPos, and yPos.

Referenced by integrateNewtonLaws().

    {
        final double k = 0.5; // in-elastic collision coefficient

        if ( xPos < barrier.xBeg ) {
            xPos = barrier.xBeg;
            vx = -k * vx;
        } else if ( xPos > barrier.xEnd ) {
            xPos = barrier.xEnd;
            vx = -k * vx ;
        }

        if ( yPos < barrier.yBeg ) {
            yPos = barrier.yBeg;
            vy = -k * vy;
        } else if ( yPos > barrier.yEnd ) {
            yPos = barrier.yEnd;
            vy = -k * vy;
        }
    }

double Particle.getKineticEnergy ( )

Gets the kinetic energy for the particle.

Returns:: the kinetic energy for the particle

Definition at line 191 of file Particle.java.

References mass, and vsq.

    {
        return mass * vsq / 2;
    }

double Particle.getX ( )

Gets the x-component of particle position.

Returns:: the x-component of particle position

Definition at line 179 of file Particle.java.

References xPos.

{ return xPos; }

double Particle.getY ( )

Gets the y-component of particle position.

Returns:: the y-component of particle position

Definition at line 185 of file Particle.java.

References yPos.

{ return yPos; }

void Particle.initBlurTrail ( int size ) [private]

Creates blur trail context (faded ghost images for particle)

Parameters:

size	trail depth (number of ghost images to show)

Definition at line 203 of file Particle.java.

References showTrail, trailFade, trailRatio, trailRatioC, trailSize, trailX, and trailY.

Referenced by Particle().

    {
        showTrail   = true;
        trailSize   = size;
        trailRatioC = 3;
        trailRatio  = 0;

        /* Create blur arrays with x,y positions and fading for ghost images
         */
        trailX    = new int  [ trailSize ];
        trailY    = new int  [ trailSize ];
        trailFade = new float[ trailSize ];

        float incrementalFactor = .2f / ( trailSize + 1 );

        for( int i = 0; i < trailSize; ++i )
        {
            /* Default values for positions -1 indicates
             * not to render these until with real values
             */
            trailX[ i ] = -1;
            trailY[ i ] = -1;

            /* The ghost is more faded as it is further away from the particle
             */
            trailFade[i] = ( .2f - incrementalFactor ) - i * incrementalFactor;
        }
    }

void Particle.integrateNewtonLaws ( double dT ) [private]

Moves the particle using numerical integration of differential equations of the motion by Euler's method.

Parameters:

dT	integration interval in seconds

Definition at line 374 of file Particle.java.

References ax, ay, forceBarrier(), WorldOfParticles.getBarrier(), vsq, vx, vy, world, xPos, and yPos.

Referenced by run().

    {
        synchronized( world )
        {
            xPos += vx * dT;
            yPos += vy * dT;

            vx   += ax * dT;
            vy   += ay * dT;

            vsq = Math.pow( vx, 2 ) + Math.pow( vy, 2 );

            forceBarrier( world.getBarrier () );
        }
    }

void Particle.interruptibleSleep ( long millis )

Thread.sleep wrapper.

Definition at line 565 of file Particle.java.

References lifeTime.

Referenced by run().

    {
        synchronized( this )
        {
            try {
                Thread.sleep( 10 );
            }
            catch( InterruptedException ie ) {
                lifeTime = 0; // kill thread
            }
        }
    }

void Particle.kill ( )

Kills the particle by setting particle's life time to 0.

Particle is dead (moving thread exits) if its life time < 0.

Definition at line 554 of file Particle.java.

References lifeTime, and mainThread.

    {
        lifeTime = 0.0;
        if ( mainThread != null ) {
            mainThread.interrupt ();
        }
    }

void Particle.makeCentripetalVelocity ( )

Makes velocity centripetal to acceleration.

Definition at line 253 of file Particle.java.

References ax, ay, vx, and vy.

    {
        vx = -ay;
        vy = ax;
    }

void Particle.moveParticle	(	double	dx,
		double	dy
	)

Moves the particle (overriding forces) and resets its velocity.

Parameters:

dx	delta x-position
dy	delta y-position

Definition at line 335 of file Particle.java.

References resetVelocity(), xPos, and yPos.

Referenced by JPWorld.keyPressed().

    {
        xPos += dx; yPos += dy;
        resetVelocity ();
    }

void Particle.paint	(	Graphics	gr,
		boolean	annotate
	)

Renders the particle in Graphics context.

Parameters:

gr	the Graphics context in which particle is rendered
annotate	indicator whether additional info about particle's acceleration is displayed or not

Definition at line 451 of file Particle.java.

References asq, ax, ay, charge, color, createParticleImage(), image, lifeTime, radius, showTrail, trailFade, trailRatio, trailRatioC, trailSize, trailX, trailY, xPos, and yPos.

    {
        if ( image == null ) {
            createParticleImage();
            if ( image == null ) {
                return;
            }
        }

        Graphics2D g = (Graphics2D)gr.create ();

        /* Convert (px,py) at the center of the particle to (x,y) as base of the image
         */
        int px = (int)xPos;
        int py = (int)yPos;
        int x = (int)( xPos - radius );
        int y = (int)( yPos - radius );

        /* Base fade for the particle is derived its life time (fades out at the end).
         */
        float baseFade = (float)( lifeTime < 0 ? 0 : lifeTime > 1 ? 1 : lifeTime );

        if ( showTrail ) {

            /* Draw previous locations of the particle as a trail of ghost images
             */
            for( int i = 0; i < trailSize; ++i ) {
                if( trailX[i] >= 0 ) {
                    /* Render each particle ghost with fading */
                    g.setComposite(
                            AlphaComposite.SrcOver.derive( baseFade * trailFade[i] )
                            );
                    g.drawImage( image, trailX[i], trailY[i], null );
                }
            }

            --trailRatio;

            if ( trailRatio <= 0 ) {

                trailRatio = trailRatioC;

                /* Shift the ghost trail positions in array (from newest to eldest)
                 */
                for( int i = trailSize - 1; i > 0; --i ) {
                    trailX[ i ] = trailX[ i - 1 ];
                    trailY[ i ] = trailY[ i - 1 ];
                }
                trailX[ 0 ] = x;
                trailY[ 0 ] = y;
            }
        }

        g.setComposite( AlphaComposite.SrcOver.derive( baseFade ) );

        if ( annotate && asq > 0.0 )
        {
            /* Vector pointing in force direction with length proportional to
             * the logarithm of acceleration (with small linear fix for dramatic purpose)
             */
            int dx = asq < 1e-9 ? 0
                : (int)( 1e-3 * ax + 3 * ax * Math.log( 1 + asq ) / Math.sqrt( asq ) );
            int dy = asq < 1e-9 ? 0
                : (int)( 1e-3 * ay + 3 * ay * Math.log( 1 + asq ) / Math.sqrt( asq ) );

            Color cText = new Color( color.getRGB () ).darker ();

            /* Draw acceleration vector
             */
            g.setColor( cText.darker () );
            g.drawLine( px, py, px + dx, py + dy );
            g.drawArc( px + dx - 4, py + dy - 4, 8, 8, 0, 360 );

            /* Show acceleration values
             */
            g.setColor( cText );
            Font f = new Font( Font.MONOSPACED, Font.PLAIN, 14 ); // TODO: static?
            g.setFont( f );
            g.drawString( String.format( "%+7.1f", ax ), px + dx - 4, py + dy - 4 - 14 );
            g.drawString( String.format( "%+7.1f", ay ), px + dx - 4, py + dy - 4 );
        }

        g.drawImage( image, x, y, null );

        if ( annotate && true )
        {
            g.setColor( Color.BLACK );
            int R = (int)( radius / 3 );
            if ( charge != 0 ) {
                g.drawLine( px - R, py, px + R, py );
            }
            if ( charge > 0 ) {
                g.drawLine( px, py - R, px, py + R );
            }
        }

        g.dispose ();
    }

void Particle.resetForce ( )

Resets total force to 0 ( so it could be summed up again).

Definition at line 262 of file Particle.java.

References Fx, and Fy.

    {
        Fx = 0; Fy = 0.0;
    }

void Particle.resetVelocity ( )

Resets velocity and acceleration for particle to 0.

Definition at line 245 of file Particle.java.

References vsq, vx, and vy.

Referenced by moveParticle().

    {
        vx = vy = vsq = 0;
    }

void Particle.run ( )

Main thread that solves Newton's laws of motion, effectively moving the particle in the parent WorldOfParticles (unless the world is paused i.e.

freezed). Thread also keeps particle's life time and after it expires, particle is removed from the belonging world.

Definition at line 585 of file Particle.java.

References WorldOfParticles.getTimeScale(), integrateNewtonLaws(), interruptibleSleep(), WorldOfParticles.isPaused(), lifeTime, WorldOfParticles.removeParticle(), and world.

    {
        final int sleepMillis = 5; // ~200 Hz

        long oldTime = System.nanoTime ();

        while( lifeTime >= 0 ) // particle is dead when its life time becomes lt. 0
        {
            interruptibleSleep( sleepMillis );
            long currentTime = System.nanoTime ();

            /* Calculates sleep time dT in seconds. dT is not necessarily the same as
             * the intentioned sleep time. It can be scaled further to speed up or
             * slow-down particle's motion.
             */
            double dT = world.getTimeScale () * (double)( currentTime - oldTime ) / 1e9;

            if ( ! world.isPaused () ) {
                integrateNewtonLaws( dT );
            }

            lifeTime -= dT;
            oldTime = currentTime;
        }

        /* Cleans-up dead particle
         */
        world.removeParticle( this );
    }
